Vibration level switch
Vibranivo® VN 7130 Vibration Level Switch Pipe Extension | UWT
Point level measurement
Liquids
The Vibranivo® VN 7130 is a Vibration Level Switch designed for accurate liquid detection. This sensor operates effectively in various types of containers, pipes, or agitator tanks, making it suitable for a wide range of applications in the food industry, breweries, dairies, the chemical and petrochemical industries, as well as in the water and wastewater sectors. The Vibration Fork allows for the switching point to be individually remote-adjusted up to 4 meters, providing enhanced flexibility in installation and operation.
Quick Setup: Save time with commissioning—no calibration required
Consistent Accuracy: Dependable measurements, unaffected by material buildup, flow, turbulence, or air bubbles
Maintenance-Free: Zero servicing costs, ensuring long-term reliability.
More Information
Measurement principle
Vibration (Fork)
Measuring task
Point level measurement
display_vn
FSH | FSL Hysteresis LED Colors Sensibility Time delay Window
Version
Pipe extension
Medium
Liquids
Mounting position
top horizontal in down Pipes in a Bypass
Ambient temperature
-40 ... 75°C | -40 ... 176°F
Process temperature
-40°C … +150°C (-40°F … +302°F)
Process pressure
-1 bar … +40 bar (-14.5 psi … +580 psi)
Minimum sensitivity
> 0,5 g/cm3
Housing type
compact
Housing material
Stainless steel 1.4404 (316L)
Housing protection rating
IP69, Type 6P
Threaded connection
≥ G 1/2" ≥ G 3/4" ≥ NPT 3/4" NPT ½"
Flange connection
≥ DN25
Hygienic fittings
≥ Triclamp 1" Flush welding socket (on G ¾" version)
Wetted materials
Stainless steel 1.4404 (316L)
Mechanical load
tube: 80 Nm
Min. immersion length
115 mm | 4.53"
Max. immersion length
4000 mm | 157"
Power supply
19 ... 230V AC/DC 10 ... 30V DC
Signal output
Transistor PNP IO-Link 2-wire without contact
Approvals
Hygienic / Pharma
EG 1935/2004 FDA EHEDG (Type EL)
Ship approval
---
Overfill protection
WHG
SIL qualification
---
Further approvals
---
Optical indicator
LED, multicolor
CE
European manufacturer approval for use in non-explosive Environments (European community)
UK
UK-Declaration of Conformity
